| Place of Origin: | CHINA MAINLAND |
| Brand Name: | Mindeoil |
| Certification: | API 5CT, API Q1, API 5B |
| Model Number: | API 5CT Casing Pipe |
| Minimum Order Quantity: | ONE CONTAINER |
|---|---|
| Price: | USD 900-1500 MT |
| Packaging Details: | In Bundle |
| Delivery Time: | 30 Working days |
| Payment Terms: | L/C, T/T, D/P, D/A |
| Supply Ability: | 10,000 MT PER MONTH |
| Grade: | API J55, K55, N80, L80, P110, C95 | Length: | R1, R2, R3 |
|---|---|---|---|
| Connection: | NUE, EUE, BTC, LTC, STC, Premium Connections | Size: | 1.9''-20'' |
| Surface Treatment: | Black Paint,varnish,customer Requirements | Certification: | API,ISO API CE |
| Outer Diameter(round): | 60.32 - 114.3 Mm,4.5 - 20 Inch | Technique: | Hot Rolled,ERW,Cold Drawn,Hot Rolled/Cold Drawn |
| Thickness: | 1.5 - 22.2 Mm | Application: | Oil Pipe,Gas Pipe,Petroleum Production |
| Standard: | API | Special Pipe: | API Pipe |
| Section Shape: | Round | Alloy Or Not: | Is Alloy |
| Standard2: | API 5CT | Grade Group: | API J55-API P110 |
| Secondary Or Not: | Non-secondary | Product Name: | Seamless OCTG 133/8 Inch P110 API 5CT Casing And Tubing,OCTG 6 5/8" API 5CT Seamless Casing Steel Pipe,Seamless Steel Pipe,Hight Quality Api Steel Line Pipe OCTG J55 Pipe,Professional Manufacture Galvanized Square Octg Line Pipe |
| Usage: | Oil Recovery,Petroleum,Industry | Type: | SMLS,api 5ct K55/J55/N80/L80/P110 Drilling,EUE,Seamless,NUE |
| Surface: | Painting | Keyword: | Casing,API 5CT Casing And Tubing For Drilling Rig,tubing |
API 5CT Seamless and ERW Casing Pipe and Tubing Pipe for Oilfield Drilling, Exploration, Well Completion and Cementing
OCTG Casing and Tubing:
After oil/gas well drilling is completed, the oil companies will arrange the contractor to RIH the casing pipe for cementing. There are usually three types of casing pipe, which are surface casing pipe,technical casing pipe and production casing pipe, many wells follow the above casing pipe assembly, and sometimes there's conductor casing pipe before the surface casing, the size is 20'' or 24'' to block the surface loose formation.
The casing pipe and tubing pipe we provide comply with API 5CT, API 5B Standard, the detailed casing pipe specification is as follows:
| Size | 4-1/2''-20'' |
| Steel Grade | API Spec 5CT J55, K55, L80, N80-1, N80-Q, L80-1, L80-9Cr, L80-13Cr, P110, C95 |
| Connections | BTC, LTC, STC, Premium Connections |
| Length | R1, R2, R3, the reguar length is R3( Our length for R3 is within 40ft, which would be easy for casing pipe loaded into 40GP containers) |
| Surface | Black Paint or Varnish |
| Packing | In Bundles |
Oil Tubing PipeSpecification is as follows:
| Size | 1.9''-4-/2'', (OD 95mm with flush joint connection is available) |
| Steel Grade | J55, K55, L80, N80-1, N80-Q, L80-1, L80-9Cr, L80-13Cr, P110, C95 |
| Connections | NUE, EUE, PE, Premium Connections |
| Length | R1, R2, R3, the reguar length is R2 |
| Packing | In Bundle |
In order to run the casing/tubing pipe to the accurate designed depth, some short tubing pipe or casing pipe pup joint will be used with length of 2', 4', 6', 8' or 10'.
For more information, please feel free to contact me, and we will provide one stop solution for OCTG Tubing and Casing Pipe.
